Define Current Gain And Voltage Gain. The voltage gain, in the product of the current gain and the ratio of the output collector resistance to the input resistance of the base circuits. Output impedance \(z_0=\frac{v_0}{i_0}= \frac{r_ci_c}{i_c}=r_c\) if r l is the load resistance, then output impedance is equal to z 0 = r c || r l.
